6 Object list
6.1. Input Process
Data (Pin 2) Ch. x
(0x2000 – 0x2FFF)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x20n0
0x01
Input Pin 2
BOOLEAN
RO
n = 0..3
0x02
Actor Short Circuit Pin 2
BOOLEAN
RO
6.2. Input Process
Data (Pin 4) Ch. x
(0x2000 – 0x2FFF)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x20n1
0x01
Actor Short Circuit Pin 4
BOOLEAN
RO
n = 0..3
0x02
Sensor supply short
circuit
BOOLEAN
RO
6.3. Additional IO-Link
Configuration
Data (Pin 4) Ch. x
(0x2000 – 0x2FFF)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x20n2
0x01
Safe State
UINT8
RW
0x02
Validation Type
UINT8
RW
n = 0..3
0x03
Parameter Server
UINT8
RW
6.4. Additional IO
Configuration
Data (Pin 2) Ch. x
(0x2000 – 0x2FFF)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x20n3
0x01
Safe State
UINT8
RW
n = 0..3
6.5. Module Status
(0x2A02)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x2A02
0x01
UA low
BOOLEAN
RO
0x02
US low
BOOLEAN
RO
0x03
no UA
BOOLEAN
RO
6.6. Output Process
Data Ch. x
(0x3000 – 0x3FFF)
(Class A only)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x30n0
0x01
Output Pin 2
BOOLEAN
RO
0x02
Restart Pin 2
BOOLEAN
RO
0x30n1
0x01
Restart Pin 4
BOOLEAN
RO
n = 0..3
6.7. IO-Link Service
Data Ch. x
(0x4000 – 0x4FFF)
Index
Sub-
index
Name
DataType
Access
Description/
Value
0x40n0
0x01
Control
UINT8
RW
0: no control
action
3: read
2: write
0x02
Status
UINT8
RO
0: no activity
1: busy
2: success
4: error
0xFF: failure
0x03
Index
UINT16
RW
0x04
Subindex
UINT8
RW
0x05
Length
UINT8
RW
n = 0..3
0x06
Data
UINT232
RW
0x07
Error Code
UINT16
RO
