3 First Steps
IO-Link Port
M12, A-coded, female
Pin
Function
Class A
Class B
1
+24V 0.2 A
+24V 1.6A
2
Input/output 2A
P24
3
0V
0V
4
IO-Link input/output 2A
Input/
IO-Link
5
n. c.
N24
Note
The digital inputs conform to the input characteristics in EN61131-2, Type 3.
Note
The IO-Link output is powered from the sensor supply.
Note
Unused I/O ports must be provided with cover caps to comply with degree of
protection IP67.
