3 First Steps
3.1. Module Overview
Figure – Overview BNI ECT-5xx-005-Z040
1 Mounting hole
2 EtherCAT™-Port 1 IN
3 Labels
4 Status LED: communication / module
5 Pin/port LED: signal status
6 Port 3
7 Port 2
8 Port 1
9 Port 0
10 Power IN
11 EtherCAT™-Port 2 OUT
12 Ground connection
12
11
5
4
3
8
6
9
7
10
1
2
1
