PCCC
Fault Log Type Length (Words) Starting Register
Fault log entry 1 (most recent)
See Fault Log Entry table below
15 232
Fault log entry 2 15 247
Fault log entry 3 15 262
Fault log entry 4 15 277
Fault log entry 5 15 292
Fault log entry 6 15 307
Fault log entry 7 15 322
Fault log entry 8 15 337
Fault log entry 9 15 352
Fault log entry 10 (oldest) 15 367
Fault Log Entry Type Length (Words) Starting Register
Timestamp UDINT 2 Offset: 0
Name Length DWORD 2 Offset: 2
Name String String 6 Offset: 4
Error Code WORD 1 Offset: 10
Advanced Error Code WORD 1 Offset: 11
Error Message Index WORD 1 Offset: 12
Reserved WORD 2 Offset: 13
System Information Type Length (Words) Starting Register
Seconds since boot UDINT 2 382
Operating mode WORD 1 384
LengthOfConfigName DWORD 2 385
ConfigName String 8 387
Config CRC WORD 2 395
EtherNet/IP Explicit Messages
Fault Log Type Length (Words) Class 0x71 Instance 1 Attribute
Fault log entry 1 (most recent)
See Fault Log Entry table below
15 1
Fault log entry 2 15 2
Fault log entry 3 15 3
Fault log entry 4 15 4
Fault log entry 5 15 5
Fault log entry 6 15 6
Fault log entry 7 15 7
Fault log entry 8 15 8
Fault log entry 9 15 9
Fault log entry 10 (oldest) 15 10
