9 Software
The Banner Safety Controller Software is an application with real-time display and diagnostic tools that are used to:
•
Design and edit
configurations
• Test a configuration in Simulation Mode
• Write a configuration
to the Safety Controller
• Read the current
configuration from the Safety Controller
• Display the real-time information, such as device statuses
• Display the fault information
The Software uses icons and circuit symbols to assist in making appropriate input device and property selections. As the
various device properties and I/O control relationships are established on the Functional View tab, the program
automatically builds the corresponding wiring and ladder logic diagrams.
See
Creating a Configuration
on page 62 for the configuration design process. See
XS/SC26-2 Sample Configuration
on
page 68 for a sample configuration design process.
See
Wiring Diagram Tab
on page 99 to connect the devices, and
Ladder Logic Tab
on page 101 for the ladder logic
rendering of the configuration.
See
Live Mode
on page 115 for the Safety Controller Run-time information.
9.1 Abbreviations
Abbreviation
8
Description
AVM Adjustable Valve Monitoring input node of the Safety Outputs
AVMx Adjustable Valve Monitoring input
BP Bypass input node of the Bypass Blocks and Muting Blocks
BPx Bypass Switch input
CD Cancel Delay input node of the Safety Outputs
CDx Cancel Delay input
ED Enabling Device input node of the Enabling Device Blocks
EDx Enabling Device input
EDM External Device Monitoring input node of the Safety Outputs
EDMx External Device Monitoring input
ES Emergency Stop input node of the Enabling Device Blocks
ESx Emergency Stop input
ETB External Terminal Block (SC10-2 only)
FID Feature identification
FR Fault Reset input node of the Safety Outputs
GSx Gate Switch input
JOG Jog Input node of the Enabling Device Blocks
IN Normal Input node of function blocks and Safety Output blocks
LR Latch Reset input node of the Latch Reset Block and the Safety Outputs
ME Mute Enable input node of the Muting Blocks and Two-Hand Control Blocks
MEx Mute Enable input
MP1 First Muting Sensor Pair input node in Muting Blocks and Two-Hand Control Blocks
MP2 Second Muting Sensor Pair input node (Muting Blocks only)
Mx Base Controller and Expansion modules (in the order displayed on the Equipment tab)
8
The "x" suffix denotes the automatically assigned number.
XS/SC26-2 and SC10-2 Safety Controllers
www.bannerengineering.com - Tel: + 1 888 373 6767 71
