Note: Saving the now confirmed
configuration is recommended. Confirmed configurations are a different
file format (.xcc) than an unconfirmed file (.xsc). Confirmed configurations are required for loading into an
SC-XM2/3 drive. Click Save As to save.
8.4.1 Notes on Confirming or Writing a Configuration to a Configured
SC10-2
User settings and passwords affect how the system responds when confirming a configuration or writing a confirmed
configuration to a
configured SC10-2 Safety Controller.
User1
1. Click Write configuration to Controller to confirm a configuration (or write a confirmed configuration) to a configured
Safety Controller.
2. Enter the User1 password.
3. The
confirmation (or writing) process begins.
At the end of the confirmation (or writing) process, the Safety Controller will have received:
• New passwords
• New
configuration
Network settings are not changed.
User2 or User3—Successful
Configuration Confirmation or Writing
This scenario assumes the following settings for User2 or User3:
• Allowed to change the configuration = enabled
• Allowed to change the network settings = enabled OR disabled
1. Click Write configuration to Controller to confirm a
configuration (or write a confirmed configuration) to a configured
Safety Controller.
2.
Enter the User2 or User3 password.
3. The confirmation (or writing) process begins.
At the end of the
confirmation (or writing) process, the Safety Controller will have received:
• New configuration
Passwords and Network settings are not changed.
User2 or User3—Unsuccessful Configuration
Confirmation or Writing
This scenario assumes the following settings for User2 or User3:
• Allowed to change the configuration = disabled
• Allowed to change the network settings = enabled OR disabled
1. Click Write configuration to Controller to confirm a configuration (or write a confirmed configuration) to a configured
Safety Controller.
2. Enter the User2 or User3 password.
3. The confirmation (or writing) process is aborted.
XS/SC26-2 and SC10-2 Safety Controllers
www.bannerengineering.com - Tel: + 1 888 373 6767 67
