Fault Code Displayed Message Additional Message Steps to resolve
4.43
Module
Communication Failure
Check module power An expansion module lost contact with the Base Controller.
4.44 – 4.45 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.46 – 4.47 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.48 Unused output Check output wiring A voltage was detected on an unconfirmed terminal.
4.49 – 4.55 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.56 Display Comm Failure -
Display Communication Failure:
• Cycle power to the Safety Controller. If fault code persists, contact
Banner Engineering (see
Repairs and Warranty Service
on page 155
4.57 – 4.59 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.60 Output Fault Check for shorts An output terminal detected a short. Check output fault for details.
13.4.2 SC10-2 Fault Code Table
Fault Code Fault Code Description Steps to resolve
1.1 – 1.2 Output Fault Replace the Safety Controller
1.3 – 1.8 Internal Fault Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155)
1.9 Output Fault Replace the Safety Controller
1.10 Output Fault
Sequence timing error:
• Perform a System Reset to clear the fault
2.1 Concurrency Fault
On a dual-channel input, or a complementary input, with both inputs in the Run state, one input
went to the Stop state then back to Run.
On a dual-complementary input, with both pairs of inputs in the Run state, one pair of inputs
went to the Stop state then back to Run.
• Check the wiring
• Check the input signals
• Consider adjusting the debounce times
• Cycle input
2.2 Simultaneity Fault
On a dual-channel input, or a complementary input, one input went into the Run state but the
other input did not follow the change within 3 seconds.
On a dual-complementary input, one pair of inputs went into the Run state but the other pair of
inputs did not follow the change within 3 seconds.
•
Check the wiring
• Check the input signal timing
• Cycle input
2.3 or 2.5 Concurrency Fault
On a dual-complementary input, with both inputs of one complementary pair in the Run state,
one input of this complementary pair changed to Stop then back to Run.:
•
Check the wiring
• Check the input signals
• Check the power supply providing input signals
• Consider adjusting the debounce times
• Cycle input
2.4 or 2.6 Simultaneity Fault
On a dual-complementary input, one input of a complementary pair went into the Run state, but
the other input of the same complementary pair did not follow the change within the time limit:
•
Check the wiring
• Check the input signal timing
• Cycle input
2.7 Internal Fault Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155)
XS/SC26-2 and SC10-2 Safety Controllers
www.bannerengineering.com - Tel: + 1 888 373 6767 151
