Page #150 background imageLoading...
Page #150 background image
Fault Code Displayed Message Additional Message Steps to resolve
3.6 EDMxx Fault Check Terminal xx Check for a short to ground
3.7 EDMxx Fault Check Terminal xx Check for a short between inputs
3.8 AVMxx Fault Perform System Reset
After this Safety Output turned Off, an AVM input associated with this output did
not close before its AVM monitoring time expired:
The AVM may be disconnected or its response to the Safety Output
turning Off may be too slow
Check the AVM input and then perform a System Reset to clear the
fault
3.9 Input Fault
AVM Not Closed When
Output Turned On
The AVM input was open, but should have been closed, when the associated
Safety Output was commanded On:
The AVM may be disconnected. Check the wiring to the AVM
3.10 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155)
4.x - - See the following table.
5.1 – 5.3 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155)
6.xx Internal Fault -
Invalid configuration data. Possible internal failure:
Try writing a new configuration to the Safety Controller
10.xx Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155)
For fault codes 4.x, check the fault log for additional faults to determine the
specific module in which the original fault
occurred.
Fault Code Displayed Message Additional Message Steps to resolve
4.1 Supply Voltage Low
Check the power
supply
The supply voltage dropped below the rated voltage for longer than 6 ms:
Check the power supply voltage and current rating
Check for an overload on the outputs that might cause the power
supply to limit the current
4.2 Internal Fault
A configuration
parameter has become corrupt. To fix the configuration:
Replace the configuration by using a backup copy of the configuration
Recreate the configuration using the Software and write it to the Safety
Controller
4.3 – 4.11 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.12 Configuration Timeout Check Configuration
The Safety Controller was left in Configuration mode for more than one hour
without pressing any keys.
4.13 Configuration Timeout Check Configuration
The Safety Controller was left in Configuration mode for more than one hour
without receiving any commands from the Software.
4.14
Configuration
Unconfirmed
Confirm Configuration
The configuration was not confirmed after being edited:
Confirm
configuration using the Software
4.15 – 4.19 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.20
Unassigned Terminal in
Use
Check Terminal xx
This terminal is not mapped to any device in the present configuration and
should not be active:
Check the wiring
4.21 – 4.34 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.35 Overtemperature -
An internal overtemperature condition has occurred. Verify that the ambient and
output loading conditions meet the specifications of the Safety Controller.
4.36 – 4.39 Internal Fault -
Internal failure—Contact Banner Engineering (see
Repairs and Warranty Service
on page 155).
4.40 – 4.41
Module
Communication Failure
Check module power An output expansion module lost contact with the Base Controller.
4.42 Module Mismatch -
The module or modules detected do not match the Safety Controller
configuration.
XS/SC26-2 and SC10-2 Safety Controllers
150 www.bannerengineering.com - Tel: + 1 888 373 6767
