Abbreviation
8
Description
MRx Manual Reset input
MSPx Muting Sensor Pair input
ONx On-Off input
OSx Optical Sensor input
PSx Protective Stop input
RE Reset Enable input node of the Latch Reset Blocks and the Safety Outputs
ROx Relay Output
RPI Requested Packet Interval
RPx Rope Pull input
RST Reset node of the SR-Flip-Flop, RS-Flip-Flop, Latch Reset Blocks, and Enabling Device Blocks
SET Set node of the SR- and RS-Flip-Flop Blocks
SMx Safety Mat input
SOx Safety Output
STATx Status Output
TC Two-Hand Control input node of the Two-Hand Control Blocks
TCx Two-Hand Control input
8
The "x" suffix denotes the automatically assigned number.
