Fault Log Entry Type Length
(Words)
Timestamp UDINT 2
Name Length DWORD 2
Name String String 6
Error Code WORD 1
Advanced Error Code WORD 1
Error Message Index WORD 1
Reserved WORD 2
System Information Type Length
(Words)
Class 0x72 Instance 1 Attribute
Seconds since boot UDINT 2 1
Operating mode WORD 1 2
LengthOfConfigName DWORD 2 3
ConfigName String 8 3
Config CRC WORD 2 4
EtherNet/IP Input Assembly
Class 4, Instance 102, Attribute 3
Fault Log Timestamp Name Length Name String Error Code Adv. Error Code Error Msg. Index Reserved
Fault log entry 1
(most recent)
0 2 4 10 11 12 13
Fault log entry 2 15 17 19 25 26 27 28
Fault log entry 3 30 32 34 40 41 42 43
Fault log entry 4 45 47 49 55 56 57 58
Fault log entry 5 60 62 64 70 71 72 73
Fault log entry 6 75 77 79 85 86 87 88
Fault log entry 7 90 92 94 100 101 102 103
Fault log entry 8 105 107 109 115 116 117 118
Fault log entry 9 120 122 124 130 131 132 133
Fault log entry 10
(oldest)
135 137 139 145 146 147 148
UDINT DWORD String WORD WORD WORD WORD
Retrieving Current Fault Information
Follow the steps below to retrieve information via network communications about a fault that currently exists:
1.
Read the
Fault Index
location to retrieve the fault index value.
2. Find the index value in the
XS/SC26-2 Fault Code Table
on page 148 or
SC10-2 Fault Code Table
on page 151 to
access a fault description and steps to resolve the fault.
PROFINET Slots (XS/SC26-2 FID 2 Only and SC10-2)
PROFINET real time data is sent and received via slots.
Note: The GSDML
file is available for download at
http://www.bannerengineering.com
.
The function of slots 1 to 17 is fixed and always active. The user-selectable data is 4 bytes. Slots 1 to 12 are for virtual
status outputs. Slots 13 to 17 are for virtual non-safety inputs. Slots 18 and 19 have selectable module data. Use the TIA
portal to activate the data for slots 18 and 19.
XS/SC26-2 and SC10-2 Safety Controllers
108 www.bannerengineering.com - Tel: + 1 888 373 6767
