2. Lenses
2. LENSES
About
Overview
• Approved Lenses
• Lens ran ge
• Replace a lens
• Lens s hift
• Locking the lens pos ition
• Adjust zoom and focus
• Adjust Iris
2.1 Approved Lenses
Approved Lenses
Partnumber Description For N orth Amrica Outside N orth america
R9801216 FLD+ 1.7 - 2.5 : 1 (EN41) approved approved
R9801226 FLD+ 0.8 : 1 (EN42) approved approved
R9801230 FLD+ 1.2 - 1.7 : 1 (EN43) approved approved
R9801211 FLD+ 2.5 - 4.6 : 1 (EN44) approved – professional us e
only
approved – professional use
only
R9801220 FLD+ Long Focus 0.8 - 1.21 :
1 (EN45)
approved approved
R9801221
FLD+ Short Focus 0.8 - 1.21 :
1 (EN46)
approved approved
R9801295
FLD+ 0.65 : 1 (EN47)
approved approved
PN_EN68
FLD+ 0.28 : 1 (EN58)
approved approved
This projector may becom e Risk Group 3 (RG 3) when an interchangeable lens with throw ratio greater than 4.7 is installed. For
Northern Ame rica, installation requirements according to Risk group 3 (RG3) must be followed w hen interchangeable lens with throw
ratio greater than 2.5 is installed.
Refer to the manual chapter 2.5 for the throw ratio versus hazard distance before operation.
2.2 Lens range
CAUTION: Alw ays rem ove the lens from the lens holder be fore mo ving or transpo rting the projector. Failure
to do this may cause damage to the lens holder and prism.
Available lenses — 4K UHD
The FLD+ (EN4X) lens rang e is custom-engineered for 4K UHD projectors.
The electrical connection to the lens motors is via a spring probe contact (pogo) pin array on the bayonet m ount. The projector will
automatically detect and identify the lens when it is installed. Automatic detection is n ot av ailable for 3rd par ty lenses.
601–0442 BALDER 13/09/2017
13
