7. Installation menu
Image 7-1
How to set the correct orientation
Select Orientation from the menu
Image 7-2
Orientation m enu path.
The o rientation menu is d isplayed
Image 7-3
Orientation M enu
Use the arrow k eys to select the Mounting and Projection positions, and press O K button to activate.
7.3 Warp
About
Image w arping is the process of digitally ma nipulating an image to compens ate for the distortion of the screen, typically by non
perpendicular alignment of the projector versus the screen. The image will then typically oc cur as shown inim age 7-4.
While an image can be transformed in various ways, pure warping doesn’t affect the colors.
42
601–0442 BALDER 13/09/2017
