4. Getting started
4.1.2.4 3G-SDI
Speci ca tions
Param eter Value
Standard SMPTE 424M-2006 10 bit lev el A
Connectors 1x) BNC 75 ohm type IEC 60169-8, Amendment 2 1997, A
Bandwidth >3 GH z
Return loss >10dB at 3GHz
Impedance 75 ohm resistive
4.1.2.5 HDBase T
Speci ca tions
Param eter Value
Reference specication HDBaseT 1.0 Specic ation, June 2010
Connector Standard R J-45, 8P 8C
Signal characteristics
HDBaseT
Max. c able length (1080p/48b/60Hz) 100 m (Cat5e/6), Pixel Clock <=225HHz, Video Datarate
<=5.3Gbps
70 m (Cat5e/6), Pixel Clock >225HHz, Video Datarate
>5.3Gbps
100 m (Cat6a/7), Pixel Cloc k >225HHz, Video Datarate
>5.3Gbps
Max TMDS Clock Frequency
270 MH z
Max video resolution supp orted
1920x1200 @60Hz (WUXG A 60Hz)
HDCP Pass-Through Yes, from S ource to Projector
IR Extension
Not Supported
RS-232 Extension Not Supported
10/100Mbps Ethernet Pass -Through Not Su pported
Fallback to 100BaseTx, IEEE 802.3u
Not Supported
USB Ove r Centre Tap Not Supported
Power Over Ethernet Not Su pported
Audio
Not Supported
LEDs - HD Base Status Operation: Green, Le ft
Link/Mode: Yellow, R ight
4.1.3 Control interfaces
About
The following control interfaces are available on the projector:
1 x RS-232 (for projector control)
1x LAN/Ethernet (for projector control
3x USB-A ports
Overview
R S -232
LAN/Ethernet
US B -A port
601–0442 BALDER 13/09/2017
31
