System manual Coronis 5MP 13
5MP2F PRODUCT5MP2F PRODUCT
5MP2F PRODUCT5MP2F PRODUCT
5MP2F PRODUCT
OVER OVER
OVER OVER
OVER
VIEWVIEW
VIEWVIEW
VIEW
The BarcoMed 5MP2F Display Controller delivers a quality 2048 x
2560 pixel image with 1024 simultaneous shades of gray for medical
imaging applications.
Features of the BarcoMed 5MP2FFeatures of the BarcoMed 5MP2F
Features of the BarcoMed 5MP2FFeatures of the BarcoMed 5MP2F
Features of the BarcoMed 5MP2F
• Dual Head Configuration
• 2048 x 2560 resolution at 60 Hz
• 8 bit performance on LCD
• 32MB Video Memory
• Portrait or Landscape Mode
• 1024 Simultaneous shades of gray
• Hardware cursor
• Single slot PCI card
• Control Panel supports the English (U.S.), Dutch, German, Korean,
Japanese, Simplified Chinese and Traditional Chinese languages
• Display properties control panel to dynamically change display
settings
Minimum System RequirementsMinimum System Requirements
Minimum System RequirementsMinimum System Requirements
Minimum System Requirements
• PCI slot with no obstructions
• Pentium II 266 MHz with 128 MB RAM (Pentium 800MHz with 256
MB RAM for cineloops)
• PCI 2.1 and/or 2.2 Compliant
• Windows NT 4.0 Service Pack 4 and above, Windows 2000
Service Pack 1 and above or Windows XP
• Displays VGA boot messages on CORONIS displays.
Supported Resolutions For Each Head of the 5MP2FSupported Resolutions For Each Head of the 5MP2F
Supported Resolutions For Each Head of the 5MP2FSupported Resolutions For Each Head of the 5MP2F
Supported Resolutions For Each Head of the 5MP2F
• 2048 x 2560 @ 60 HZ (primary)
• 2560 x 2048 @ 60 Hz
The following resolution is also available when the OS is booted in
VGA mode.
• 640x480 @ Default Refresh Rate, 16 colors
