15. Removal and installation of the projector covers

15.10 Installation of the t op cover

Necessary tools

7mm ﬂ at screwdriver.

How to install the top c over?

1. Install the top cover on the projector.

2. Fas ten the four captive screws (reference 1 image 15-14) of the top cover using a 7m m ﬂat screwdriver.

Image 15-14

R5977692 DP2K-S SERIES 10/12/2012 129
