Barco RLM W6 - RGB Connection

21
RGB connection
Connect your PC or other devices with RGB output to the RGB input connectors on the
projector to be used as the source of image input.
S-VIDEO VIDEO YUV 1
RGB-S
RGBHV / YUV 2
G/Y B/Pb R/Pr H V
RS-232
12V TRIGGER
IR ext.
RGB-HV/SOG
AC MAINS
100-240 Volts
50/60Hz
AC POWER SWITCH
HDMI
 HDMI 
I II
350mA

Desk Top or Notebook
Connect to a wall outlet
S-VIDEO VIDEO YUV 1
RGB-S
RGBHV / YUV 2
G/Y B/Pb R/Pr H V
RS-232
12V TRIGGER
IR ext.
RGB-HV/SOG
HDMI
 HDMI 
I II
350mA
Desk Top or Notebook
Installing the projector
4
