Barco RLM W6 - Adjusting the Projector Lens

26
Rear projection - desktop installaion
Press MENU  ALIGNMENT  Rear Projection and choose ON; the projector is
now configured for "rear projection - desktop installation".

canoe
Correct Picture
canoe

canoe
Rear projection - ceiling mode
Press MENU  ALIGNMENT  Rear Projection and choose ON;
press MENU once more  ALIGNMENT  Ceiling Mode and choose ON
canoe
canoe


Correct Picture
canoe
Adjusting the projector lens
Projector lens adjustment includes focus, zoom, horizontal/vertical image shift. Please refer
to Chapter III on "Quick installation of the projector > Adjusting projector angle, Adjusting
projector focus/zoom, Correcting keystoning caused by projection angle" for detailed
instructions.
4
Installing the projector
