Barco RLM W6 User Manual

5
Hg
For more information, please contact Electronic Industries Alliance (WWW.EIAE.
ORG).
For information on proper lamp handling, visit WWW.LAMPRECYCLE.ORG.
Warning and Safety Instructions
Special Care for Laser Beams!
Special care should be considered when DLP projectors and high power laser equipment are
used in the same room as.
Direct or indirect hit of a laser beam on to the projector lens can severely damage the Digital
Mirror Devices (DMD™).
Sun light Warning
Avoid using the RLM W6 in direct sun light.
Sun light on the projector lens can severely damage the Digital Mirror Devices (DMD™).
Never look into the projector light source directly
This equipment contains a high brightness light source and a portion
of the light emitted by the projector is ultraviolet light. Never look into
the projector light source directly and pay special attention to prevent
children from looking into the projector light source as it can damage
their eyes.
AVOID EYE CONTACT TO THE LIGHT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with an arrowhead within a triangle
is intended to tell the user that inside this product
may cause risk of electrical shock to persons.
The exclamation point within a triangle is intended to tell
the user that important operating and/or servicing instructions
are included in the technical documentation for this equipment.
CAUTION / TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
Do not turn off the projector by unplugging the power cord.
Under normal operations, be sure to use the SOFT POWER button to turn off the projector as
the internal cooling fans will remain working for approximately 90 seconds after the projector
has been turned off for the shutdown proccess to be completed. And as such, avoid shutting
off AC power to turn off the projector since it could lead to lamp malfunctioning or damage.
Electric shock
To protect your projector, avoid turning on the projector during lightning storms and unplug it
from the wall outlet. This will prevent sudden electrical surges caused by the lightning from
damaging the projector.
Warning, Notices and Safety Instructions
1

Barco RLM W6 Specifications

General

Matrix size	0.67 \
Heat dissipation	2900 BTU/h
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	2200:1
Digital gamma correction	Yes
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	516.7 x 669.74 x 247 mm
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1200 pixels
Focal length range	- mm
Vertical lens shift range	0 - 100 %
Horizontal lens shift range	-30 - 30 %
Lamp power	330 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Noise level	39 dB
Preset modes	sRGB, Standard
Certification	FCC, CE EN55022 Cl. A, CE, TUV, WEEE.
Dot clock scanning frequency	165 MHz
Full HD	No
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	850 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	AC, HDMI-DVI
Remote control type	IR
Sustainability certificates	RoHS

Weight and Dimensions

Depth	669.74 mm
Width	516.7 mm
Height	247 mm
Weight	26000 g
Package weight	30000 g
