Barco RLM W6 User Manual

29
OSD Menu Tree
OSD Menu
Tree
INPUT
Input Selection
HDMI1
HDMI2
RGB D-15(RGB-HV/
SOG)YUV1(RGB-S)
RGBHV/YUV2
Composite Video(Video)
S-Video
RGB-S
Input Locking
Auto
48Hz, 50Hz, 60Hz
Auto Power Off
On
Off
Auto Power ON
On
Off
No Signal
Logo
Blue
Black
White
Video Standard
Auto
PAL, SECAM, NTSC
Auto Image
Adjust
Off, Auto
Always
Contrast 0~200
Brightness 0~200
Saturation 0~200
Tint 0~200
Sharpness 0~200
Noise Reduction 0~200
Color
Temperature
3200K, 5400K, 6500K,
9300K, Native
Input Balance
Black Balance Offset
Red Offset
Green Offset
Blue Offset
White Balance
Red Gain
Green Gain
Blue Gain
Aspect Ratio
5:4 , 4:3, 16:10
16:9, 1.88, 2.35
Letterbox, Native
Timings
H Total
H Start
H Phase
V Start
Auto Image Execute
LAYOUT
Zoom
Off
Crop
Zoom
Main Select
HDMI1
HDMI2
RGB D-15(RGB-HV/
SOG)YUV1(RGB-S)
YUV2(RGBHV/YUV2)
Composite Video(Video)
S-Video
RGB-S
PIP Select
HDMI1
HDMI2
RGB D-15(RGB-HV/
SOG)YUV1(RGB-S)
YUV2(RGBHV/YUV2)
Composite Video(Video)
S-Video
RGB-S
PIP Position
Top Left
Top Right
Botton Left
Botton Right
Split L-R
PIP On, Off
LAMPS
Mode
Eco
Normal
Power
LAMPS
Single
Dual
High Altitude
Mode
On
Off
Power 0~22
Lamp1 Status
On
Off
Lamp2 Status
On
Off
Lamp1 Run Time XX HRS
Lamp2 Run Time XX HRS
6
OSD Menu description

Barco RLM W6 Specifications

General

Matrix size	0.67 \
Heat dissipation	2900 BTU/h
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	2200:1
Digital gamma correction	Yes
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	516.7 x 669.74 x 247 mm
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1200 pixels
Focal length range	- mm
Vertical lens shift range	0 - 100 %
Horizontal lens shift range	-30 - 30 %
Lamp power	330 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Noise level	39 dB
Preset modes	sRGB, Standard
Certification	FCC, CE EN55022 Cl. A, CE, TUV, WEEE.
Dot clock scanning frequency	165 MHz
Full HD	No
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	850 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	AC, HDMI-DVI
Remote control type	IR
Sustainability certificates	RoHS

Weight and Dimensions

Depth	669.74 mm
Width	516.7 mm
Height	247 mm
Weight	26000 g
Package weight	30000 g
