Barco RLM W6 User Manual

49
Service
BARCO RLM W6
INPUT IMAGE LAYOUT LAMPS ALIGNMENT CONTROL SERVICE
Model : RLM W6
Serial Number : 1688886661220
Software Version : MP02-GP02-0001-00
Active/PIP Source : HDMI 1 / RGB D-15
Pixel Clock zHM 79.351:
Signal Format : 1920x1200@60Hz
H/V Refresh Rate : H: 74.019 KHz V: 60 HZ
Lamp1 Run Time : 122 HRS
Lamp2 Run Time : 88 HRS
retnEteseR ruoH pmaL
Projector Run Time : 1268 HRS
> nO < ylno eulB
Factory Reset Enter
Service
The functions covered in this unit relate to the display of some basic information about the
projector.
*Memory of the custom timing les will be erased in the Factory Reset operation.*
•
Model: the designated model number of the projector.
•
Serial Number: the designated serial number of the projector.
•
Software Version: the version of software installed on the projector.
•
Active/PIP Source: displays the current PIP sources.
•
Pixel Clock: displays the pixel clock of the current input signal.
•
Signal Format: displays the format of the current input signal.
•
H/V Refresh Rate: displays the horizontal and vertical refresh rates for the current image.
•
Lamp1 Run Time: displays Lamp1's current run time.
•
Lamp2 Run Time: displays Lamp2's current run time.
*Notice! When a lamp's run time has reached 1500-2000 hours or when you notice the projected image to
be noticeably dimmer, please replace the lamp.*
•
Projector Run Time: displays the projector's total operating hours.
Lamp Hour Reset
Use this function to reset the hours for lamp1 and lamp2 to zero.
* After replacing the lamp, remember to reset the lamp hours to ensure the accuracy of lamp hours
displayed in the OSD Menu.*
Blue Only
Enabling this option will make the projector display only blue color to facilitate the process
of image inspection for the service personnel. For detailed instructions on how to use this
function, consult a qualified service personnel.
Factory Reset
Use this function to restore the configurations in the OSD Menu back to factory default.
Note that this function will not apply to items including no signal, network, Projector
control, startup Logo, language, High Altitute mode and lamp hours.
*When Factory Reset is executed, all source memories created by the projector (i.e. timings les) will be
erased.*
