47
Network
To control the projector via network, after connecting the network cables for a PC and the
projector, you can use this OSD function to view the relevant network information (such as IP
Address, Subnet Mask, Gateway and DHCP) of the projector. Please configure the PC to be
connected to the projector with a proper IP address with the same subnet mask, gateway as
the projector. The default IP address of the projector is 192.168.0.100. The network settings
of the projector can only be changed through the web-page control or projector Toolset
application.
Menu Position
You can use this function to designate which area on the image the OSD Menu will appear.
As you can see from the diagram below, there are five positions where you can choose to
have the OSD Menu displayed.The default setting is "Center".
Top Left
Center
Bottom Left
Top Right
Bottom Right
Start Up Logo
You can use this function to have the projector display the Barco logo in the start up screen.
Set On to display the Barco logo during start up and Off to display a blank image.
Start Up Chime
Set it to On to have the projector play a sound effect during start up; when it is set to off, the
projector will not play any sound effect to indicate start up.
Button 1~5
Use this function to designate the image source for each corresponding button.
For example, if you have assigned Button 1 as HDMI1 and Button 2 as RGB-S,
when you press
1
on the remote control, the projector will show the image from HDMI1.
when you press
1
on the remote control, the projector will switch to the image from
RGB-S.
You can choose from eight different input sources on the projector, namely: HDMI1, HDM2,
RGB D-15(RGB-HV/SOG), YUV1(RGB-S), YUV2(RGBHV/YUV2), Composite Video(Video),
S-Video, and RGB-S.
6
