Barco RLM W6 User Manual

30
OSD Menu description
6
ALIGNMENT
Rear Projection
On
Off
Ceiling Mode
On
Off
Lens Control
Zoom/Focus
Shift
Keystone
Horizontal Keystone
Vertical Keystone
Dynamic
Contrast
On (1~12 Pattern)
Off (0 off)
Gamma
1.8 2.0 2.2
2.35 2.5
Internal Patterns
On
Off
Color Space
Native, EBU, SMPTE
Custom
Lens To
Midposition
Execute
Control
IR Address
1
2
Eco Network
Power
On
Off
Projector Control
RS-232
Network
Network
IP Address
Subnet mask
Gateway
DHCP
(these are read-only
information)
Menu Position
Top Left
Top Right
Botton Left
Botton Right
Center
Start Up Logo
On
Off
Start Up Chime
On
Off
Button 1
HDMI1
HDMI2
RGB D-15(RGB-HV/
SOG)YUV1(RGB-S)
YUV2(RGBHV/YUV2)
Composite Video(Video)
S-Video
RGB-S
Button 2
Button 3
Button 4
Button 5
Trigger 1
5:4 , 4:3, 16:10
16:9, 1.88, 2.35
Letterbox, Native, Auto
Trigger 2
Auto Source
On
Off
Control Language
English
French
Spanish
German
Portuguese
Chinese Simplied
Chinese Traditional
Japanese
Korean
Service
Model
Read-only information
Serial Number
Software Version
Active/PIP source
Pixel Clock
Signal Format
H/V Refresh Rate
Lamp1 Run Time
Lamp2 Run Time
Lamp Hour Reset
Lamp1 Hour Reset
Lamp2 Hour Reset
Projector Run
Time
Read-only information
Blue Only
On
Off
Factory Reset
The command will
be executed after
conrmation in the prompt
dialog box

Barco RLM W6 Specifications

General

Matrix size	0.67 \
Heat dissipation	2900 BTU/h
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	2200:1
Digital gamma correction	Yes
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	516.7 x 669.74 x 247 mm
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1200 pixels
Focal length range	- mm
Vertical lens shift range	0 - 100 %
Horizontal lens shift range	-30 - 30 %
Lamp power	330 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Noise level	39 dB
Preset modes	sRGB, Standard
Certification	FCC, CE EN55022 Cl. A, CE, TUV, WEEE.
Dot clock scanning frequency	165 MHz
Full HD	No
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	850 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	AC, HDMI-DVI
Remote control type	IR
Sustainability certificates	RoHS

Weight and Dimensions

Depth	669.74 mm
Width	516.7 mm
Height	247 mm
Weight	26000 g
Package weight	30000 g
