R5912128 /03 SP4K-B128
12.1 Removal of the front cover
If the front cover is the only cover you need to remove (e.g. when checking / replacing the filter),
there is no need to turn off the projector.
Required tools
No tools required.
How to remove
1. Slide the front cover to the side of the Input & Communication Unit and remove it.
Note: The handles do not click open. They are fixed into the cover.
Image 12–1 Sliding the front cover away from the projector
Projector Covers
