Barco SP4K-B - Removal of the Sealed Compartment Side Cover

R5912128 /03 SP4K-B132
12.5 Removal of the sealed compartment side
cover
Required tools
Torx screwdriver T20
How to remove
1. Remove the light source side cover.
2. Remove the two screws of the sealed compartment side cover. Use a T20 Torx screwdriver.
3. Lift up and remove the side cover.
Tip: It may be necessary to move the cover a bit towards the rear side in order to properly
remove it.
Image 12–6 Removal of the mains side cover
