R5912128 /03 SP4K-B28
Image 2–4 Removing corner foam blocks
9. Mount 4 M10 eyebolts in the foreseen openings in the top cover, as illustrated in the following image.
Image 2–5 Example of eye bolts mounted in the top cover
10. Lift the projector from the pallet using a hoisting tool.
Image 2–6
Caution: Take into account the weight of the projector when manipulating the projector. For this
reason, make sure to only use a hoisting or lifting tool to lift up and move the projector.
Make sure to provide a hoisting or lifting tool capable of lifting and moving the projector to its
designated position.
Getting started
