49R5912128 /03 SP4K-B
Tip: In case of mono phase wiring (which only has L, N and PE), The L wire should be
connected to the rightmost of the three phase terminals (reference 5). However, ensure that you
correctly connect the PE (reference 4) and the neutral wire (reference 6).
4. Secure the AC power cord by fastening the cable gland (reference 3). Use a 30 mm open-end wrench.
5. Place the net input cover back and seal it. Tighten the two screws (reference 1), using a T20 Torx
screwdriver.
Physical installation projector
