7. MAIN ULTRASOUND SCREEN
After starting the system, the main ultrasound screen will appear.
An explanation of the various parts of the main ultrasound screen is provided below.
7.1. Information Bar
The information bar is located at the top of the ultrasound screen. This bar contains the following information:
Image Depth Scale
Main Toolbar
Information Bar
Catheter Icons
Depth Markers
Cue™ Needle Tracking
System Activator Icon
(if enabled - see
Section 9)
Patient Information
Time
File Management
Date
Catheter Trim Length
Exit Site Marking
Battery Information
