Image Acquisition Control
104 Basler pilot
Formula 2:
Calculates the maximum frame rate based on the exposure time for the acquired frames:
Where:
The constant C
3
depends on the camera model as shown in the table below:
For more information about setting the exposure time, see Section 8.4 on page 91.
Formula 3:
Calculates the maximum frame rate based on the frame transmission time:
For the related formula when the averaging feature is used, see Section 11.9 on page 173.
C
3
piA640-210gm/gc 46.99 µs
piA1000-48gm/gc 95.57 µs
piA1600-35gm/gc 79.64 µs
piA1900-32gm/gc 139.38 µs
piA2400-12gm/gc 102.40 µs
piA2400-17gm/gc 81.92 µs
Note
When the averaging feature is used, the above formula is replaced by the
related formula in the "Averaging" section, which may permit a higher
maximum acquisition frame rate.
Max. Frames/s
1
Exposure time in µs C
3
+
------------------------------------------------------------------=
Max. Frames/s
Device Current Throughput Parameter Value
Payload Size Parameter Value
------------------------------------------------------------------------------------------------------------------------=
