Parameter
Parameter manual b maXX
®
1000
Document no. 5.07004.03
29
of 208
4
P0077
The motor auto tuning procedure will set this parameter. The user may also set this pa-
rameter without using the auto tuning procedure, see ZP0850–.
P0110
The rated current of the drive ZP0054– is regarded as 100 %. The setting of the motor
no-load current will affect the slip compensation.
The setting value must be less than ZP0054–.
P0111
Refer to the rated rpm and the number of polepairs on the type plate of the motor and use
the following equation to calculate the rated slip:
Rated slip (Hz) = F
Motor nominal frequ.
( ZP0061–) - (rated rpm ⋅ motor pole pairs ⋅ 120)/60
This parameter is valid only in vector mode.
ZP0111– can be calculated via ZP0124– automatically if unknown. ZP0111– can be
changed only if ZP0124– = 0.
P0112
This parameter may be set so that the drive will increase its voltage output to obtain a
higher torque. Only to be used for V/f control mode.
P0077
Motor Ständerwiderstand 0 to 65535 mΩ abc
EE Motor line-to-line resistance 0 mΩ abc
STOP BM_u_MotorStatorResist 1:1abc -
P0110
Motor Leerlauf-Strom 0.0 to 99.0 % ZP0054–
EE Motor no-load current 40.0 % ZP0054–
ON BM_u_MotorNoLoadCurrent 10:1 -
P0111
Motor Nennschlupf 0.00 to 20.00 Hz
EE Motor rated slip (Motor nominal slip) 3.00 Hz
STOP BM_u_MotorRatedSlip 100:1 -
P0112
Drehmomentanpassung 0.0 to 10.0 Hz
EE Torque compensation 0.0 Hz
ON BM_u_TorqueComp 10:1 -
NOTE
Too high torque compensation can overheat the motor.
