1 2 3 4 5 6 7 8 9 10
ON
DIP switch
32 1 Value
1 1 1 7 Option module CA
Nopen slave for b maXX PLC
DIP switch
10987654 Value Node-ID
0000110 6 7
Description of Option Module CANopen slave
Instruction handbook CANopen slave BM4-O-CAN-03
Document no. 5.02014.06
21
of 68
4
Example 1: DIP switch setting for b maXX PLC
NOTE
The Node-ID set by DIP switches can be changed via the application program on the b maXX
PLC.
1 2 3 4 5 6 7 8 9 10
ON
DIP switch
32 1 Value
0 1 1 3 Option module CA
Nopen slave for b maXX controller
Baud rate 500 kBit/s
DIP switch
10987654 Value Node-ID
0000100 4 5
Example 2: DIP switch setting
for b maXX controller
