INSTRUCTIONS FOR FITTERS
Consumption 15°C-1013 mbar
24 -1.24 24 F - 1.24 F
( ( ( (
Rated power 2,78 m
3
/h 2,04 kg/h 2,73 m
3
/h 2,00 kg/h
Reduced power 1,12 m
3
/h 0,82 kg/h 1,12 m
3
/h 0,82 kg/h
p.c.i. 34,02 MJ/m
3
46,34 MJ/kg 34,02 MJ/m
3
46,34 MJ/kg
Table of burner injectors
24 -1.24 24 F - 1.24 F
gas type G20 G31 G20 G31
diameter of nozzles (mm) 1,18 0,77 1,28 0,77
Burner pressure (mbar*)
REDUCED HEAT OUTPUT
2.5 5,4 2,0 5,7
Burner pressure (mbar*))
RATED HEAT OUTPUT
13,1 29,3 11,2 32,6
N° nozzles 13
Consumption 15°C-1013 mbar
1.14 1.14 F
( ( ( (
Rated power 1,63 m
3
/h 1,20 kg/h 1,60 m
3
/h 1,17 kg/h
Reduced power 0,75 m
3
/h 0,55 kg/h 0,75 m
3
/h 0,55 kg/h
p.c.i. 34,02 MJ/m
3
46,34 MJ/kg 34,02 MJ/m
3
46,34 MJ/kg
Table 2
1.14 1.14 F
gas type G20 G31 G20 G31
diameter of nozzles (mm) 1,18 0,77 1,18 0,77
Burner pressure (mbar*)
REDUCED HEAT OUTPUT
1.8 4,0 2,0 4,2
Burner pressure (mbar*)
RATED HEAT OUTPUT
8,0 17,7 8,5 19,1
N° nozzles 10
* 1 mbar = 10,197 mm H
2
O
Table 1
