BEC 8920AC User Manual
3. LAN Connection
Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side to the
PC’s Ethernet interface.
4. WAN Connection
4.1 xDSL Interface
For single line xDSL, please connect the supplied Y-Cable or a regular RJ-11 phone cable to the
DSL port and the other side to the phone jack on the wall.
