15
Roller shutter
Drives
Information
PicoR+ drives with electronic limit
switching detect and program the upper
limit position automatically.
In order for the drive to detect the upper
limit position correctly, a defined stop must
be present (angled strip or mechanical
stop).
The springs are attached to the mini
tube using tube clamps. This stops the
springs from rubbing against the drive.
The limit positions can be set using any
operator control.
Limit positions are deleted using the
programming unit.
Connect the wires in the connecting
cable of the drive to the wires of the
same colour in the programming unit.
