16
Programming the limit positions
1. Programming the upper limit
position
First, run the roller shutter towards
the upper limit position until the drive
switches off automatically.
Note: For safety reasons, the drive
uses less force when opening the
shutter for the first time (installation
run). If the force is borderline, the
drive may stop before reaching the
upper limit position. After resetting
(deletion of the limit positions), the
drive is restarted until it reaches the
upper limit position.
2. Programming the lower limit
position
Now run the roller shutter to the desired
lower limit position.
(If anti-lifting devices or rigid safe-
ty springs are installed, run the roller
shutter downwards until the drive stops
automatically.)
PicoR+ drives
