Page #122 background imageLoading...
Page #122 background image
Configuration
EP31xx122 Version: 2.4
Index 800E AI Internal data Ch. 1
Index (hex) Name Meaning Data type Flags Default
800E:0 AI internal data Maximum subindex UINT8 RO 0x01 (1
dec
)
800E:01 ADC raw value Raw value of the analog/digital converter INT16 RO 0x0000 (0
dec
)
Index 800F AI Vendor data Ch. 1
Index (hex) Name Meaning Data type Flags Default
800F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
800F:01 offsetU Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:02 gainU Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
800F:03 offsetI Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:04 gainI Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
800F:05 offsetI4 Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:06 gainI4 Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
Index 801E AI Internal data Ch. 2
Index (hex) Name Meaning Data type Flags Default
801E:0 AI Internal data Ch. 2 Maximum subindex UINT8 RO 0x01 (1
dec
)
801E:01 ADC raw value Raw value of the analog/digital converter INT16 RO 0x0000 (0
dec
)
Index 801F AI Vendor data Ch. 2
Index (hex) Name Meaning Data type Flags Default
801F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
801F:01 offsetU Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:02 gainU Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
801F:03 offsetI Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:04 gainI Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
801F:05 offsetI4 Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:06 gainI4 Gain (vendor calibration) INT16 RW 0x4000
(16384
dec
)
Index F000 Modular device profile
Index (hex) Name Meaning Data type Flags Default
F000:0 Modular device profile General information for the modular device profile UINT8 RO 0x02 (2
dec
)
F000:01 Module index distance Index distance of the objects of the individual channels UINT16 RO 0x0010 (16
dec
)
F000:02 Maximum number of
modules
Number of channels UINT16 RO EP3162-0002:
0x0002 (2
dec
)
EP3182-1002:
0x0003 (3
dec
)
Index F008 Code word
Index (hex) Name Meaning Data type Flags Default
F008:0 Code word reserved UINT32 RW 0x00000000
(0
dec
)
Index F010 Module list (EP3162-0002)
Index (hex) Name Meaning Data type Flags Default
F010:0 Module list Maximum subindex UINT8 RW 0x02 (2
dec
)
F010:01 SubIndex 001 UINT32 RW 0x0000012C
(300
dec
)
F010:02 SubIndex 002 UINT32 RW 0x0000012C
(300
dec
)
