Beckhoff EP31 Series User Manual

Configuration
EP31xx126 Version: 2.4
Index 8020 AI Settings (parameterization of channel 3)
Index (hex) Name Meaning Data type Flags Default
8020:0 AI Settings Maximum subindex UINT8 RO 0x18 (24
dec
)
8020:01 Enable user scale 1 User scale is active. BOOLEAN RW 0x00 (0
dec
)
8020:02 Presentation 0 Signed presentation BIT3 RW 0x00 (0
dec
)
1 Unsigned presentation
2 Absolute value with MSB as sign (signed
amount representation)
8020:05 Siemens bits 1 Status indicators are displayed on the lowest
3bits in the status word.
BOOLEAN RW 0x00 (0
dec
)
8020:06 Enable filter 1 Enable filter, which makes PLC-cycle-synchro-
nous data exchange unnecessary
BOOLEAN RW 0x01 (1
dec
)
8020:07 Enable limit 1 1 Limit 1 enabled BOOLEAN RW 0x00 (0
dec
)
8020:08 Enable limit 2 1 Limit 2 enabled BOOLEAN RW 0x00 (0
dec
)
8020:0A Enable user calibra-
tion
1 Enables user calibration BOOLEAN RW 0x00 (0
dec
)
8020:0B Enable vendor cali-
bration
1 Enable vendor calibration BOOLEAN RW 0x01 (1
dec
)
8020:0E Swap limit bits 1 Swaps the two limit bits, in order to achieve
compatibility with older hardware versions.
BOOLEAN RW 0x00 (0
dec
)
8020:11 User scale offset User scale offset INT16 RW 0x0000 (0
dec
)
8020:12 User scale gain User scale gain.
The gain is represented in fixed-point format, with the
factor 2
-16
.
The value 1 corresponds to 65535
dec
(0x00010000
hex
)
and is limited to +/- 0x7FFFF
INT32 RW 0x00010000
(65536
dec
)
8020:13 Limit 1 First limit value for setting the status bits INT16 RW 0x0000 (0
dec
)
8020:14 Limit 2 Second limit value for setting the status bits INT16 RW 0x0000 (0
dec
)
8020:15 Filter settings This object shows the digital filter settings. The filter
settings can only be read here. They are set via
channel1 [}124] for all channels of the module.
UINT16 RW 0x0000 (0
dec
)
0 50Hz FIR
1 60Hz FIR
2 IIR 1
3 IIR 2
4 IIR 3
5 IIR 4
6 IIR 5
7 IIR 6
8 IIR 7
9 IIR 8
8020:17 User calibration offset User calibration: Offset INT16 RW 0x0000 (0
dec
)
8020:18 User calibration gain User calibration: Gain INT16 RW 0x0000 (0
dec
)
