Beckhoff EP31 Series User Manual

Configuration
EP31xx 127Version: 2.4
Index 8030 AI Settings (parameterization of channel 4)
Index (hex) Name Meaning Data type Flags Default
8030:0 AI Settings Maximum subindex UINT8 RO 0x18 (24
dec
)
8030:01 Enable user scale 1 User scale is active. BOOLEAN RW 0x00 (0
dec
)
8030:02 Presentation 0 Signed presentation BIT3 RW 0x00 (0
dec
)
1 Unsigned presentation
2 Absolute value with MSB as sign (signed
amount representation)
8030:05 Siemens bits 1 Status indicators are displayed on the lowest
3bits in the status word.
BOOLEAN RW 0x00 (0
dec
)
8030:06 Enable filter 1 Enable filter, which makes PLC-cycle-synchro-
nous data exchange unnecessary
BOOLEAN RW 0x01 (1
dec
)
8030:07 Enable limit 1 1 Limit 1 enabled BOOLEAN RW 0x00 (0
dec
)
8030:08 Enable limit 2 1 Limit 2 enabled BOOLEAN RW 0x00 (0
dec
)
8030:0A Enable user calibra-
tion
1 Enables user calibration BOOLEAN RW 0x00 (0
dec
)
8030:0B Enable vendor cali-
bration
1 Enable vendor calibration BOOLEAN RW 0x01 (1
dec
)
8030:0E Swap limit bits 1 Swaps the two limit bits, in order to achieve
compatibility with older hardware versions.
BOOLEAN RW 0x00 (0
dec
)
8030:11 User scale offset User scale offset INT16 RW 0x0000 (0
dec
)
8030:12 User scale gain User scale gain.
The gain is represented in fixed-point format, with the
factor 2
-16
.
The value 1 corresponds to 65535
dec
(0x00010000
hex
)
and is limited to +/- 0x7FFFF
INT32 RW 0x00010000
(65536
dec
)
8030:13 Limit 1 First limit value for setting the status bits INT16 RW 0x0000 (0
dec
)
8030:14 Limit 2 Second limit value for setting the status bits INT16 RW 0x0000 (0
dec
)
8030:15 Filter settings This object shows the digital filter settings. The filter
settings can only be read here. They are set via chan-
nel1 [}124] for all channels of the module.
UINT16 RW 0x0000 (0
dec
)
0 50Hz FIR
1 60Hz FIR
2 IIR 1
3 IIR 2
4 IIR 3
5 IIR 4
6 IIR 5
7 IIR 6
8 IIR 7
9 IIR 8
8030:17 User calibration off-
set
User calibration: Offset INT16 RW 0x0000 (0
dec
)
8030:18 User calibration gain User calibration: Gain INT16 RW 0x0000 (0
dec
)
Index F800 AI Range Settings (EP3174/EP3184 from firmware version 04)
Index (hex) Name Meaning Data type Flags Default
F800:0 AI Range Settings Maximum subindex UINT8 RO 0x04 (4
dec
)
F800:01 Input type Ch1 Input signal range for channel 1 UINT16 RW 0x0000 (0
dec
)
0 -10V...+10V
1 0mA...20mA
2 4mA...20mA
6 0V...10V
F800:02 Input type Ch2 Input signal range for channel 2 (values see chan-
nel1)
UINT16 RW 0x0000 (0
dec
)
F800:03* Input type Ch3 Input signal range for channel 3 (values see chan-
nel1)
UINT16 RW 0x0000 (0
dec
)
F800:04* Input type Ch4 Input signal range for channel 4 (values see chan-
nel1)
UINT16 RW 0x0000 (0
dec
)
F800:05 Enable Filter Set-
tings Per Channel
BOOLEAN RW -
