Beckhoff EP31 Series User Manual

Configuration
EP31xx 137Version: 2.4
Index 800F AI Vendor data
Index (hex) Name Meaning Data type Flags Default
800F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
800F:01 R0 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:02 R0 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
800F:03 R1 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:04 R1 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
800F:05 R2 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
800F:06 R2 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
Index 801E AI Internal data
Index (hex) Name Meaning Data type Flags Default
801E:0 AI internal data Maximum subindex UINT8 RO 0x01 (1
dec
)
801E:01 ADC raw value Raw value of the analog/digital converter INT16 RO 0x0000 (0
dec
)
Index 801F AI Vendor data
Index (hex) Name Meaning Data type Flags Default
801F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
801F:01 R0 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:02 R0 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
801F:03 R1 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:04 R1 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
801F:05 R2 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
801F:06 R2 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
Index 802E AI Internal data
Index (hex) Name Meaning Data type Flags Default
802E:0 AI internal data Maximum subindex UINT8 RO 0x01 (1
dec
)
802E:01 ADC raw value Raw value of the analog/digital converter INT16 RO 0x0000 (0
dec
)
Index 802F AI Vendor data
Index (hex) Name Meaning Data type Flags Default
802F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
802F:01 R0 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
802F:02 R0 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
802F:03 R1 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
802F:04 R1 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
802F:05 R2 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
802F:06 R2 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
Index 803E AI Internal data
Index (hex) Name Meaning Data type Flags Default
803E:0 AI internal data Maximum subindex UINT8 RO 0x01 (1
dec
)
803E:01 ADC raw value Raw value of the analog/digital converter INT16 RO 0x0000 (0
dec
)
Index 803F AI Vendor data
Index (hex) Name Meaning Data type Flags Default
803F:0 AI vendor data Maximum subindex UINT8 RO 0x06 (6
dec
)
803F:01 R0 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
803F:02 R0 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
803F:03 R1 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
803F:04 R1 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
803F:05 R2 Offset Offset (vendor calibration) INT16 RW 0x0000 (0
dec
)
803F:06 R2 Gain Gain (vendor calibration) INT16 RW 0x4000 (16384
dec
)
