PN A51387AB
2-11
Software Overview
Instrument Toolbar Buttons
2
Instrument Toolbar Buttons
The Instrument Toolbar is located at the bottom of the Multisizer 4 software window, below the
Viewing Area.
Instrument Toolbar buttons duplicate functions also available in the Run drop-down menu. The
buttons are divided into three sections:
•
(
Run
)
buttons
•
(
Reset
)
button
•
(
Fluid control
)
buttons
Instrument Toolbar: Run Buttons
The Instrument Toolbar Run buttons allow you to preview, start, repeat, stop, pause, resume,
continue, or cancel an analysis run.
Table 2.5 Instrument Toolbar: Run Buttons
Click... To...
(
Preview
)
Preview an analysis run to check concentration. If you adjust the
concentration, the Analyzer automatically continues the preview run when
you shut the Sample Compartment door.
(
Start
)
Start an analysis run.
(
Repeat
)
Repeat an analysis run with the same settings.
(
Pause
)
Pause an analysis run.
(
Resume
)
Resume an analysis run after pausing.
If you pause a 30-second timed analysis after 10 seconds, the
(
Resume
)
button will run only the 20-second remainder of the analysis time. If you
pause a run and then press
(
Continue
)
, the software will re-run the 30-
second analysis with your original settings, and add the data to the data
already gathered during the abbreviated 10-second analysis.
(
Continue
)
Continue a run from the beginning, adding the data to data previously
gathered from a run with the same settings.
(
Cancel
)
Cancel an analysis run.
If you click the
(
Cancel
)
button, the software will cancel the run and
display Run Canceled above the analysis in the Viewing Area. You will not
be able to save data from the analysis.
(
Stop
)
Stop an analysis run.
If you click the
(
Stop
)
button, the software will stop the analysis currently
in progress and display Run Complete above the analysis data in the
Viewing Area. You can save the analysis file.
