Note 3
NOTES:
Replace emergency locator
At emergency locator
-
transmitter battery
1 . Anytime the control surfaces are altered, repaired, or repainted, they must be re-
balanced per the Shop Manual.
2 . Check the wing bolts for proper torque at the first 100-hour inspection and at the
first 100-hour inspection after each reinstallation of the wing attach bolts.
3 . Rechargeable Batteries: Recharge after one cumulative hour of use or after 50% of
the useful charge life.
Non-rechargeable Batteries: Replace after one cumulative hour of use or after 50%
of the useful charge life.
tLubricate aileron control rod ends in place using SAE 20 or SAE 10W30 or remove aileron
control rod assembly, clean and relubricate control rod ends using MIL-G-23827 grease. Ro-
tate rod end bearings to assure adequate lubricant coverage. Check aileron rigging after re-
installation of rod end assembly.
t tlightly saturate felt seals with 1 OW30 oil (remove excess by pressing slightly) also coat the
sides and outer diameter with the same type of grease used on the bearings.
