I
Section VII BEECH
CRAFT
Baron58
SystemsDescription Serial TH
773
and After
For ventilation during ground operation, push the CABIN
AIR control forward and place the three-position switch on
the pilot's subpanel in the BLOWER position. An optional
fresh air blower (Serials TH-1225 and after) located in the
aft fuselage provides additional ventilation through the
overhead
outlets
during
ground
operations,
and
automatically shuts off in flight.
INDIVIDUAL FRESH AIR OUTLETS
Fresh ram air from the intake on the left side of the dorsal
fairing is ducted to individual outlets above each seat,
including the optional fifth and sixth seats. A master control
in the overhead panel just aft of the front air outlets
enables the pilot to adjust the amount of ram air available
to all outlets. The volume of air at each outlet can be
regulated by rotating the outlet. Each outlet can be
positioned to direct the flow of air as desired.
OXYGEN SYSTEM
WARNING
Proper safety measures must be employed
when using oxygen, or a serious fire hazard
will be created. NO SMOKING PERMITIED.
DESCRIPTION
The recommended masks are provided with the system.
The masks are designed to be adjustable to fit the average
person.
The oxygen cylinder is located at the aft end of the forward
baggage compartment. The system is available with either
four, five, or six outlets and with a 49.8 or 66 cu ft oxygen
bottle. Supply of oxygen to the system is controlled by a
push-pull control on the pilot's subpanel. The pressure
indicator shows the supply of oxygen available (1850 psi is
nominal pressure for a full supply in the cylinder).
7-36
February, 1981
