QUICKFIRE® WRAP AROUND
1MANUL825 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 37
Installation
Installing Cleaning Material
Upper Hub: Neo-Tex®
7) Locate 12 of the 25” x 8” x 1/4” thick Neo-Tex® pieces and twelve 8” Wash Clips.
8) Place the Wash Clips ends through the holes of the packs.
9) Fill every third “C” Channel slot as shown below (12 pieces in all). Make sure the Packs are
pushed down as far as possible. Be sure the flaps are in the right direction.
Fill every third slot
24 (25” x 8”
x 1/8” thick)
Pieces of Neo-Tex® , 2
per clip
12 Wash Clips
Fill every third slot
12 (25” x 8” x 1/4” thick)
Pieces of Neo-Tex® , 1
per clip
12 Wash Clips
To Next Page
