QUICKFIRE® WRAP AROUND
52 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL825
Installation
Utility Connections for Side Wheels: Electric
Water Feeds
7) Connect a 1/2” water feed to the barbed hose fittings on each Boom as shown below.
Note: It is imperative that no foreign materials are in the supply lines before final connections
are made. To be sure of this, the lines should be blown out prior to final hookup.
Field supplied clamp
Field supplied 3/4“ water supply
To Next Page
