Bend-Tech Dragon mAchines User Manual

24 Bend-Tech Dragon
Troubleshooting Guide
Toolhead & Tools Troubleshooting
03
03
Laser Light & Engraver
Troubleshooting
3.1 Laser Light Troubleshooting
Important
The Laser Light is a consumable. If the Laser Light quits working it may have
reached the end of its service life. Contact Bend-Tech to order a new Laser Light.
3.1.1 Laser Light does not Align with the End of the Material
Material length Set Wrong
Check the material length, verify length is correct in software project settings.
Chuck Grip Setting are Wrong
Verify the Chuck grip setting is correct in Dragon CAM > Tube Library > Machine > Chuck Grip.
Click the question mark to see examples of Chuck Grip settings.
Machine Not Homed or Calibrated Correctly
From the Bend-Tech Dragon home interface click Machine Control, then click HOME ALL
AXIS to home the Dragon. If it is determined the machine needs to be calibrated, a full
calibration can be performed by clicking into Machine Library, and in the Main interface click
the WIZARD icon.
3.1.2 Laser Light Failure
Laser Light Burned Out
Replace the Laser Light. Contact Bend-Tech for options available.
