56 Bend-Tech Dragon
Troubleshooting Guide
Mach3
09
10
Troubleshooting Mach3
10.1 Diagnostics in Mach3
10.1.1 Mach3 License Data
The Mach3 license data is located in the upper left corner of the Mach3 interface. This license
data is used by Bend-Tech Support to help troubleshoot the Dragon machine from the Bend-
Tech Service Center.
10.1.2 Coordinating Dragon Designations With Mach3
In some cases it may be necessary to coordinate the Dragon Machine Control homing system
with Mach3 software user interface.
Mach3 uses ++ and - machine limit labeling system in its user interface. These are prefaced by
a numbered order preceded by the letter M.
Per Dragon programming, the “- -” designations in Mach3 are considered home.
Note
When homing the Dragon, when the green Home symbol lights up it should briey light up the
corresponding M Home designation in Mach3.
