User interface FP200-NGRM
34
NGRM7xx_D00292_07_M_XXEN/02.2022
Tab. 6.1: Legend, FP200-NGRM
Device buttons
7 Navigates up in a list or increases a value.
8
MENU Opens the device menu.
ESC
Cancels the current process or navigates one step back in the
device menu.
9
RESET Resets alarms.
Navigates backwards (e.g. to the previous setting step) or selects
parameter.
10
TEST Starts the device self test.
Navigates forwards (e.g. to the next setting step) or selects param-
eter.
11
INFO Shows information.
Navigates down in a list or reduces a value.
12
DATA Indicates data and values.
OK Confirms an action or a selection.
13 X1
Interface X1 (see
page 29 ff. for more details)
14 ETH Ethernet interface
15 R on/off Terminating resistor for A/B (Modbus RTU)
Buzzer Active in case of alarm and/or test
Rear side
REMOTE RJ45 port for connection of FP200-NGRM to enclosure
X3 Without function
No. Description Explanation
