7.9.6 System settings (menu 6.6)
Tab. 7.7: System settings (menu 6.6)
Menu Parameter
Setting
range
Explanatory notes
6.6.1
Ground-
fault relay
Mode (6.6.1.1)
Fail-safe,
non-fail-safe
1)
Relay test (6.6.1.2) on, off 2)
6.6.2
NGR-fault
relay
Mode (6.6.2.1)
Fail-safe,
non-fail-safe
1)
Relay test (6.6.2.2) on, off 2)
6.6.3 Trip relay
Mode (6.6.3.1)
Fail-safe,
non-fail-safe
1)
Relay test (6.6.3.2) on, off 2)
6.6.4 Analogue
Mode (6.6.4.1)
0…20 mA
4…20 mA
0…400 µA
0… 10 V
2… 10 V
3)
Function (6.6.4.2)
I
NGR,
R
NGR
6.6.5
Digital
inputs/
outputs
Device OUT
(6.6.5.1)
Fail-safe,
non-fail-safe
1)
Pulser OUT
(6.6.5.2)
Fail-safe,
non-fail-safe
Digital 1 (6.6.5.3)
configurable
Pulser/NGR
method
Active high
Active low
Active high: Activation of the func-
tion when input level changes from
"low" to "high"
Active low: Activation of the func-
tion when input level changes from
"high" to "low"
RESET IN (6.6.5.4)
TEST IN (6.6.5.5)
6.6.6 Buzzer
Buzzer alarm
(6.6.6.1)
on, off
on: each alarm activates buzzer
off: alarm does not activate buzzer
Buzzer test
(6.6.6.2)
on, off
on: test activates buzzer
off: test does not activate buzzer
