13.3 Ordering details

13.3.1 NGR monitor

*When using the "transparent front cover 144x72 (IP 65)" the cutout in the switchboard

cabinet must be extended in height from 66 mm to 68 mm (+0.7/-0 mm). The degree of

protection IP65 applies only to the user interface FP200-NGRM when using the front

cover. The degree of protection for the complete device is still IP30.

13.3.2 Accessories

Measuring current transformers

Voltage supply (for CTUB103… measuring current transformers)

Type

Supply voltage/Frequency range U

Art. No.

NGRM700

AC 24…240 V, 40…70 Hz

DC 24…240 V

B94013700

NGRM750 B94013750

Accessory for FP200-NGRM: Transparent front cover 144x72 (for IP65)* B98060005

Voltage/Current Type Art. No.

AC up to 10 A W20 B98080003

AC up to 25 A

W35 B98080010

W60 B98080018

W0-S20 B911787

W1-S35 B911731

W2-S70 B911732

AC/DC up to 10 A CTUB103-CTBC35 B78120030

AC/DC up to 25 A

CTUB103-CTBC60 B78120031

CTUB103-CTBC120 B78120032

max. connected current

transformers

Type Art. No.

2 STEP-PS/1 AC/24 DC/0.5 B94053110

7 STEP-PS/1 AC/24 DC/1.75 B94053111

17 STEP-PS/1 AC/24 DC/4.2 B94053112
