PL-6000DC/DCX Two-Post Parking Lift 45 P/N 5900273 — Rev. A6 —July 2024
Route the Control Panel wires through the Control Arm into the Powerside Post, then up and out
through a hole near the top of the Powerside Post. See figure below.
Run the Control Box wires through the Powerside Post and then into the Junction Box on the
Power Unit. See Control Panel Wiring Diagram for reference.
