BenQ PX9510 - Lens Shift Adjustable Range

English
19
200 5.08 170 4.31 106 2.69 614.7 15.6 926.4 23.53 915.9 23.26 1434.7 36.44 129.7 3.29 162.1 4.12
300 7.62 254 6.46 159 4.04 924.0 23.47 1392.1 35.36 1379.6 35.04 2157.8 54.81 195.4 4.96 244.0 6.20
400 10.16 339 8.62 212 5.38 1233.9 31.34 1857.9 47.19 1843.3 46.82 2880.9 73.18 261.2 6.63 325.9 8.28
500 12.70 424 10.77 265 6.73 1543.7 39.21 2323.6 59.02 2307.1 58.60 3604.0 91.54 326.9 8.30 407.7 10.36
Lens shift adjustable range
The adjustable range for lens shift is tabulated below and subject to the conditions listed.
The drawings below apply to the standard lens only.
Desk Front Projection
Ceiling Mount Front Projection
Vertical Shift
Vertical Shift
Height of projected image
Height of projected image
Max
0.5V
Max
0.5V
1V
1V
Normal projection position
Shift to Left Shift to Right
Width of projected image
0.1H 1H 0.1H
